• 4.3" IP/HD Analog / Analog Tester by Tatung

4.3" IP/HD Analog / Analog Tester

TLM-43IPC

    • 4.3" LCD Touch Screen Display (800 x 480)

    • Supports ONVIF and ONVIF PTZ

    • Built in Wi-Fi, 10/100M LAN Port (receive images from wireless camera)

    • IP Discovery, quickly search IP address

    • Audio In/Out, Recording and Storage

    • Video playback/snapshot, Magnify 4xZoom the image display and video output for detailed viewing

    • Removable micro SD Card - 8GB Micro SD card, capture and save the current video or screenshot the image and save as jpeg file on the SD card

    • Support more than 80 customized IP camera protocols, such as HIKVISION, Dahua, KED, Samsung, Tiandy camera etc.

Description

The 4.3" touch screen IP camera monitor and tester is designed for maintenance and installation of IP camera and analog camera as well as other security equipment. 800 x 480 resolution enables it to display network HD cameras and analog cameras in high resolution.
The tester is also a great tool for Ethernet network testing. It can test PoE power voltage, PING and IP address searching. You can use the blue cable tracer to locate individual connected cables from a bundle of cables.
Test LAN cable for proper connection termination. Other functions include providing 24W PoE power to your camera., LED Flashlight, DC 12V 2A power output and much more. It's portability, user -friendly design and many other functions make the IP tester an essential tool for all installers or technicians.


Specifications

Model No

TLM-43IPC

Screen Size

4.3"

Backlight System

LCD

Resolution

800 x 480 Pixels

Brightness

400 cd/m²

Viewing Angle (L / R / U / D)

50° / 50° / 35° / 45°

Aspect Ratio

5 : 3

Contrast Ratio

200 : 1

Response Time

15 ms

Input Connectors

HD CVI - 1 channel input (BNC interface), support resolution: 720p 25,30,50,60 fps/ 1080p 25,30fps - zoom, video, record and playback, coaxial PTZ control and call camera OSD Menu
HD TVI - 1 channel input (BNC interface), support resolution: 720p 25,30,50,60 fps/ 1080p 25,30fps zoom, video, record and playback, coaxial PTZ control and call camera OSD Menu
HD SDI -1 channel input (BNC interface) , support resolution: 720p 25, 30fps/ 1080p 25,30fps - record and screen snapshot
AHD - 1 channel input (BNC interface) , support resolution: 720p 25, 30fps/ 1080p 25,30fps- zoom, video, record and playback, coaxial PTZ control and call camera OSD Menu
Audio - 1 channel input and 1 channel output to connect headphones. You can test audio input from aduio pickup devices by connecting the aduio pickup device t othe IP tester with the supplied audio cable

Output Connectors

HDMI (support 1080P), PoE Power, DC12V/2A power for camera, USB power 5V 2A (USB is not meant for data). You can use the USB power when the IP Tester is turned off to power an external USB device.

Internal Battery

Built-In Lithium Ion Polymer Battery / 5000mAh, up to 15 hours

Power Input

12 VDC

Power Consumption

< 3.6 Watts

Charging Time

6 hrs

Operating Time (Continuously)

5 hrs

Net Weight

1.81 lbs

Gross Weight

4.41 lbs

Note Specifications subject to change without notice
